Parameters
1. Sensor: RGB 1080P 1/4 inch CMOS
2. Lens: 3.6mm standard lens
3. Resolution: 1080P (1920×1280), 720P (1280×720) optical
4. Gimbal angle: horizontal: 355 degrees, pitch: 120 degrees
5. Minimum sensitivity: 0.02Lux
6. Infrared night vision: up to 10 meters, 4 array lights + 4 white lights
7. Compression method: H.264 dual stream
8. Video stream: 1080P: 1.2-1.5Mbps, 720P: 512Kbps
9. Audio format: G.711A
10. WiFi protocol: IEEE 802.11b/g/n
11. Power supply: E27 110-240V
12. Working temperature: -10 – 55 degrees Celsius
13. Working humidity: 10% – 80% (no condensation)
14. TF storage: maximum support 128G TF card (not including TF)
15. APP: Yiiot
Features
1. 2 million pixel high-definition image, intelligent dual-light full-color night vision
2. Support alarm recording, all-day recording
3. Support mobile phone remote monitoring, you can check the monitoring situation at any time
4. Support video control / two-way voice / motion detection / automatic tracking / alarm push, etc.
5. Easy to install, suitable for various scenarios
Specification:
|
General
|
| Power Supply |
110-240V, 50/60Hz (Input) |
| Performance |
Motion detection, Night Vision, Alarm detection, Two Way Audio, Alarm Function |
|
|
Network
|
| Wireless |
WiFi 802.11 b/g/n |
|
|
System / Hardware
|
| Sensor Size |
1/4 inch Progressive Scan |
| Image Flip Function |
Horizontal Flip, Vertical Flip |
| Pan/Tilt-Horizontal Angle |
355 degrees |
| Pan/Tilt-Vertical Angle |
120 degrees |
|
|
Media Format
|
| Video Compression Format |
H.264 |
| Audio Compression Format |
G.711A |
|
|
Night Vision
|
| Configuration |
4 array LEDs |
|
|
Physical Environment
|
| Operate Temperature |
-10 to 55 Degree Celsius |
| Working Humidity |
10 to 80 percent |
|
|
Package Weight
|
| One Package Weight |
0.30kgs / 0.66lb
|
| One Package Size |
17cm * 8cm * 8cm / 6.69inch * 3.15inch * 3.15inch
|
| Carton Weight |
13.00kgs / 28.66lb
|
| Carton Size |
42cm * 36cm * 40cm / 16.54inch * 14.17inch * 15.75inch
|
| Loading Container |
20GP: 440 cartons * 50 pcs = 22000 pcs
40HQ: 1023 cartons * 50 pcs = 51150 pcs
|
|
